- Size: 2.8
- Place of Origin: Guangdong Foshan
- Brand Name: Dikai
- Model Number: dk-420
- Weight: 350.000 kg
Combination called fully automatic matching series DK-420A/520A/620A/720A
Unit constitution
1, SY series mainframe 20 computer combination weighing 3 Z type material conveyor
4 vibration feeder 5 support platform 6 finished conveyor
Two, the main performance and structural characteristics
1 automatic completion of feeding, measuring, filling, date printing and product output of the whole process;
2 high precision, high efficiency, no broken material.
Three, the scope of application
Suitable for bulk objects with high measurement precision and fragile packaging, such as puffed food, crispy rice, jelly, candy, pistachio, apple slices, Boiled dumplings, Glutinous Rice Balls, chocolate, hardware, medicine etc..
Four, technical specifications
型号 | DK-420A | DK-520A | DK-620A | DK-720A |
耗气量 | 0.65Mpa.3m3/min.6kg/cm2 | 0.65Mpa.4m3/min. 6kg/cm2 | ||
包薄膜宽度 | Max.420mm | Max.520mm | Max.620mm | Max.720mm |
制袋长度 | 80-300mm | 80-350mm | 100-400mm | 100-500mm |
制袋宽度 | 80-200mm | 100-250mm | 150-300mm | 180-350MM |
卷材最大外径 | Max.360mm | Max.360mm | Max.360mm | Max.360mm |
包装速度 | 5-80bags/min | 5-70bags/min | 5-55bags/min | 5-80bags/min |
薄膜厚度 | 0.04-0.08MM | 0.04-0.08MM | 0.04-0.08MM | 0.04-0.08MM |
电源规格 | 220V.50/60Hz.3KVA | 220V.50/60Hz.3KVA | 220V.50/60Hz.3KVA | 220V.50/60Hz.3KVA |
外型尺寸 | (L)960(W)930(H)1600mm | (L)1430(W)1200(H)1700mm | (L)1780(W)1300(H)1950mm | (L)1800(W)1310(H)2050mm |
机器重量 | 450kg | 650kg | 700kg | 750kg |
